Rugged | Versatile | performance

offshore sportfishing | cruising

STANDARD EQUIPMENT

12 Year structural hull warranty ·  “No wood” Construction ·  Color or White gelcoat hull w/ painted boot stripe ·  Cored deck and molded hull liner with White or two tone molded non-skid (Gray/Tan) ·  Foam filled composite grid stringer system ·  High density foam cored transom ·   High impact SS rub rail insert

DECK

Molded bow sprit w/ roller, chain lock & hawse pipe  ·   Anchor windlass w/ forward foot controls with freshwater washdown ·   Stainless steel bow rail 1.25” ·   (5) Stainless steel hand rails ·   Stainless steel deck hardware ·

PILOTHOUSE

Custom fiberglass windshield frame ·   Coated windshields & sliding side windows w/ screens ·   (3) Pantograph wipers w/ multifunction switch and washers  ·  (2) Stainless Steel Vent hatches on hard top ·   LED navigation lights, docking lights, courtesy lights & dome lights ·   Dual trumpet horn ·   PYI Seaview Mast ·  Wood Trim ·   Portside Settee and Wood Table ·   Aft Bulkhead BiFold Windows with locking door ·

HELM

Ritchie compass  ·   EDSON Stainless Steel Wheel ·   RELEASE Double Helm Seat ·   Yamaha Display ·  YachtSense control panel ·  Windlass switch ·  Zip Wake Trim tabs LED position indicators ·   Wetsounds Stereo entertainment system ·  Bowthruster control ·   Throttle controls and HelmMaster Joystick ·   USB & DC plugs

NAVIGATION ELECTRONICS

Control Screen YachtSense Digital Switching System ·  *2) Raymarine Axiom 2XL 19” Multi-function displays •RMK-10 Remote · Cyclone 110 watt 4’ Open Array Radar ·   VHF Radio · Teledyne FLIR M364C Premium Multispectral Marine Camera · CAM300 Marine Camera · AR200 Stabilization Augmented Reality · RVM T/H 20Degree Transducer · Real Vision MAX 3D sonar · Down vision · Side vision · AIS 700 ·

GALLEY

Refrigerator and  Freezer drawers ·  Solid surface countertop · Two burner 1200w electric stove top ·  Stainless steel sink ·  Microwave drawer

COCKPIT

Aft facing Cockpit Seat to Port ·  Insulated cooler below seat ·  (2) 75GAL In deck Macerated Fish boxes or Storage compartments (P&S) ·   (6) Custom stainless rod holders ·  (2) Stainless rod / cup holders ·  Cockpit bolster package w/ NorthCoast logo ·  Fresh water shower at transom  ·  Saltwater wash down  ·  Removable cockpit sole ·  Center access cockpit hatches w/ gas assisted struts ·  Full cockpit perimeter gutter system w/ oversized scuppers  ·  Port Side Cockpit door ·  (2) Transom 29 GAL Blue Live wells w/ light & clear lid ·  Transom door starboard side ·   Armstrong Bracket with swim ladder ·  2) 8” and 2) 6” speakers

MASTER CABIN

Mahogany wood veneer bulkhead ·   Queen berth w/ rod storage below ·   7 1/2" Custom inner-spring Mattress   ·  Hanging locker portside ·  Pull out drawers ·  Stainless Steel Overhead opening Hatch ·   Stereo Cabin Speakers (2) 6” ·  LED reading lights ·  110GFI outlet ·  Storage lockers to port ·  Opening ports w/ screens (4) ·  Fwd hatch w/ screen  ·  Wood flooring and steps

AFT CABIN/CREW QUARTERS

Double Aft berth below helm area  ·  6 1/2" hinged Mattress ·   Single berth portside  ·  6 1/2" hinged Twin Mattress ·  Storage below single berth  ·   LED reading lights ·  Night stand with solid surface and drawers between berths  ·  Mid cabin seat portside ·        LED reading lights ·  Drawers below seat ·  USB Charging port ·  110GFI outlet · Opening port with screen · Wood flooring

HEAD

Electric Head, 36gal. holding tank, macerator ·  LED cabin dome lights (day/night) ·  110V GFI outlets ·  Separate shower w/ glass partition, comfortable seat and Rule 800 Sump System ·  3/4" Teak grate ·  Vessel sink ·  Tissue holder and Mirror  · Opening port with screen

MECHANICAL

Bowthruster 3kw ·   Seakeeper 4 ·  ZipWake trim tabs ·  10k btu Air Conditioning Dometic / Reverse cycle heat Cabin area below ·  18k btu Air Conditioning Dometic / Reverse cycle heat in Pilothouse ·   Generator 9kw w/ 36GAL Diesel tank ·   Inline Blower Rule 240 ·   (2) Automatic bilge pumps 2200GPH ·  100GAL Fresh water combined tanks ·   Pressure Hot & Cold water system

ELECTRICAL

(4) 31M-AGM battery system ·   (2) 4D House battery ·  50AMP Shore power ·  AC/DC panel at helm  ·  50' Shore power chord ·   UBS & DC plugs ·   110V GFI outlets at galley & head ·   110V outlets in cabin & at helm ·   Courtesy lights ·   Battery Charger Xplore 120 ·   Galvonic Isolator

ADDITIONAL FACTORY OPTIONS

• Cockpit Rocket Launcher on pedestal

• Outriggers Rupp Tournament Style

• EVA Decking Cockpit Fishing

• Cruising Package includes Cockpit Seating

• Cockpit Table with deck plate insert

• EVA Decking Cockpit Cruising

*Standard Raymarine Electronics Description:

For an immersive boating experience and fingertip control of all systems, the helm is equipped with two Axiom 2XL 19-inch multi-function displays with a RMK-10 remote. Anglers will appreciate the RealVision MAX 3D sonar with exceptionally clear CHIRP DownVision™ and SideVision™ sonar. The boat’s Cyclone Pro 110-watt four-foot open array radar delivers superior target separation and long-range resolution using CHIRP pulse compression and Raymarine beam sharpening technology. An AR200 supplies GPS position, compass heading, pitch and roll data to Axiom chartplotters and when combined with the onboard FLIR M364C premium multispectral marine camera and CAM300, the AR200's video stabilization capabilities enable ClearCruise™ Augmented Reality features. Raymarine’s AIS offers complete situational awareness. Raymarine’s YachtSense™ digital switching modular backbone supports a complete electronics suite with easy-to-use tools that put owners in total command of the vessel’s systems, with lighting, pumps, hydraulics, and HVAC systems all integrated for simple touch screen control.

For more information on Raymarine and its full line of marine products and digital switching solutions, visit www.raymarine.com.

Options, freight & taxes extra. Prices, specifications, equipment and options may change without notice.

Please contact your nearest dealer for pricing.

designer notes:

Boat designers when partnering with a successful company must always ask themselves: "What aspects of the existing models do you keep, and what do you evolve?" When the team at NorthCoast asked us to complement the company's successful line of sportfishing boats with a new 40-foot flagship fit for family cruising, they set one parameter from the get-go that made our job easier: "We love the ride of our boats, and we don't want to mess with that." So, when designing the hull lines, that was priority No. 1.

The hull sports a deep V with 24.62 degree base dead rise at the transom (19.47 degree Hydrodynamic dead rise), while keeping a subtle round-off at the keel, which gives the hull a little more lift aft and allows for a smoother transition to planing. The hull's volume is optimized to handle the multiple outboards hung on a bracket off the transom—a typical feature of NorthCoast's boats and a popular approach in this market. The top speed with Quad Yamaha 300’s will be more than 50 MPH. We had a bit more leeway above the waterline: We were asked to keep the 415 within the spirit of the existing line, which we did by softening the sharp lines of the smaller models while still giving the pilothouse its characteristic feel: The high point of the coaming sits just forward of the windshield and slopes down aft, mirroring the rugged sheerline shape that is a NorthCoast trademark. The profile will look right at home in the large swells of the Atlantic and turn heads as the boat returns to harbor.

We designed the interior layout in close collaboration with the team at NorthCoast. The goal was to develop an interior worthy of a flagship model for this line. At this size, a master berth forward, with access from both sides, is a must. A second queen-sized berth sits under the pilothouse to starboard, and a settee to port can also serve as a bunk. The head is large enough that there is room for a separate shower stall. The pilothouse represents new territory for the NorthCoast line since it is their first fully enclosed pilot house with a full salon, galley, and helm station. The aft window and house door can be opened to create a continuous indoor/outdoor area.

The 415 will come in two versions. One is aimed squarely at the sportfishing market, which is at the core of the NorthCoast brand, while the other will be tailored to family coastal cruising.

One reason we are excited about this new design is our partnership with the family business that produces NorthCoast boats, C&C Marine. Jose DaPonte, his wife Rosa, and his sons Cesar and Craig, and key employees are intimately involved in the development and production. Every part and detail gets discussed from the multiple viewpoints in the room: Does it fit the brand? Will it look good? Can we build it efficiently? Is this how we want to do this? Decades of experience come through in these discussions—Jose and his team have hand-built almost every mold in the shop. Even after the boats leave the factory, the team has a habit of maintaining close relationships with customers. This new flagship will no doubt continue their tradition of personal dedication to quality, performance, and value—traits worth keeping, even as other aspects evolve.

—Thomas Degremont & Sam Howell, Langan Design Partners

Cruising Cockpit option: video below shows Table and molded seat configuration
