ULTIMATE FISHING PERFORMANCE



RUGGED | VERSATILE | PERFORMANCE

NorthCoast NEW 255 all business hull can run across the wave tops with a wide-open throttle of 56 miles per hour!  Sporting a 22 Degree dead-rise and 9’5” Beam, the new 255 handles inshore or offshore conditions like a champ, running dry and comfortable- as you would expect from a NorthCoast. 159 usable gallons of fuel at 3000rpms | cruising at 25MPH | *12.9GPH and a conservative range of 268NM nautical miles or 302 statute miles.

We listened to those asking for the new model to be larger than the 235 with a private head, sink to wash up, and comfortable accommodations for two. For serious anglers you’ll arrive at the fishing grounds faster and enjoy a longer and wider cockpit to fight big fish- which you can bring aboard via through the walk thru transom door.

With two 35 gallon macerated in-deck Fish boxes, self-draining deck, 26 gallon transom Blue lighted Live Well, 105 quart transom storage box, 2 tackle storage bins, and drawers, 113 quart cooler under the portside seat, cubbies for wallets and 12volt USB adapters, and a helm with room for two 12” touch screens. Opening windshields, and side windows let fresh air abound with windshield wipers port and starboard. This platform is rugged, versatile, and focuses on fishing performance- exceptional!

*Range and fuel economy is estimated and will vary based upon load and sea state


255 Feature Call Out 255 v2.png

BORN FOR THE HORIZON

STANDARD EQUIPMENT 255

12 Year structural hull warranty ·  “No wood” construction · White hull w/ boot stripe · Cored deck and molded hull liner w/two tone molded non-skid (Choice of Gray or Tan) · Foam filled composite grid stringer system · High density foam cored transom · Armstrong dual engine bracket · High impact rub rail w/ insert

DECK

Bow rail 1” Stainless steel ·  Running lights ·  Molded bow sprit w/ anchor roller, chain lock & hawse pipe ·  Stainless steel bow chocks ·  Stainless steel ½” bow & stern eyes (3) ·   Stainless steel 10” bow & stern cleats (3) ·  Stainless steel 8” pop-up spring line cleats (2) ·  Stainless steel fuel fill deck plate ·  Courtesy lights

PILOTHOUSE

Custom fiberglass windshield frame ·  Opening windshields & sliding side windows w/ screens ·  Wipers w/multifunction switch P&S · EDSON SS steering wheel ·  Horn ·  Todd Helm and Companion seats P&S ·  Insulated 113 quart Cooler under cushion aft of companion seat·(2) Tackle boxes P&S w/tool drawers ·  (2) Folding cup holders · LED navigation lights, courtesy lights & dome lights ·  Ritchie compass @ helm ·  DC panels at helm w/USB & DC plugs ·  LEMCO Trim tabs w/ LED position indicators ·  Seat cushions P&S- aft of seats ·  Phone, wallet, key bins outboard of helm seats, P&S Custom aft canvas enclosure w/roll up door

CABIN

75” Berth length with 40” sitting headroom & cushions ·  Storage lockers and pull out drawer to port (optional Galley package available) ·  Locking Companionway door ·  Opening ports w/ screens (2) ·  Forward hatch w/ screen Bomar 19x19 · LED cabin dome lights (day/ Red night)

PRIVATE HEAD

Marine Head macerated overboard discharge and holding tank ·  Vanity sink, w/pull out shower sliding door storage/shelves ·  LED cabin dome lights (day/Red night) ·  Courtesy light

COCKPIT

LED Cockpit Floodlight ·  Courtesy lights P&S ·  Walk through transom door portside ·  26 Gal transom Blue Live well w/ light & clear lid ·  Transom compartment with knife holder/cutting board ·  (4) Custom Stainless rod holders · (2) Cup holders ·  (2) 139 quart Macerated Fish boxes in deck ·   Under gunnel rod holder storage P&S (6) ·  Cockpit bolster package w/NorthCoast logo ·  Saltwater wash-down ·  Storage in steps to foredeck P&S ·  Center access cockpit hatches w/ gas assisted struts ·   Full cockpit perimeter gutter system w/oversized scuppers ·  Armstrong Swim ladder

MECHANICAL

(3) AGM Battery system ·  Pressure cold water system · Automatic Rule bilge pump FWD 1100GPH ·  Automatic Rule bilge pump AFT 2000GPH

 ADDITIONAL FACTORY OPTIONS
• Hull color $3,250

• Rocket launchers on hard top  $1,472

• Rocket launchers on transom $1,472

• Outriggers Rupp Top Gun $3,530

• Additional rod holders (Pair) $185

• Electric head system $3,320

• Shore power package includes: $2,525

AC/DC panel at helm w/ UBS & DC plugs

110V GFI outlets at galley & head

110V outlets in cabin & at helm Shore power chord

• Inverter $975

• Air conditioning* Dometic  $9,929

• Generator (Gas) $18,318

• Galley package: $5,835

Stainless steel AC/DC fridge, sink, microwave

• Anchor windlass w/foot controls $1,825

• Upgrade Helm and Comp Seats $2,430

• Folding Cockpit Seat $2,195

• Gray rub rail  $350

• Wet Sounds Stereo and speakers $1,410

• Outboard HP: T200 |T250

*Requires Shore Power option

Options, freight & taxes extra. Prices, specifications,equipment and options may change without notice.

Please contact your nearest dealer for pricing.

boat design notes:

"We are so proud to offer this new 255HT. I know you’ll be pleased whether you plan to fish it hard or go cruising once in a while. This boat actually has a private stand alone head below and sleeps two comfortably. The hull is designed beautifully to be dry and soft in the worst conditions. Our niche is that we build real boats, for real boaters, without all the fluff. It should make NorthCoast Owners very proud when they step aboard- and probably sad to leave when they go home."- Jose DaPonte, Owner of NorthCoast Boats / C&C Fiberglass Inc.

This new 255 is all about being rugged, versatile, and performing beyond expectation and can be equipped with all the important features required by inshore or offshore fishermen. We provide all the tools you need to fish. The cockpit is uncluttered and massive- with two large in deck fish boxes.

The 255 is built for speed to get you to the offshore grounds quickly and comfortably. Although her quality is seen, the feeling of a solid boat under your feet is reassuring when offshore with friends or family, as weather conditions can sometimes deteriorate, your confidence to keep fishing is founded in NorthCoast Boats solid reputation.

255 fuel.png
